AUDIO SPECIFICATIONS AND FEATURES
Stereo Power 125 watts/ch, 20Hz – 20kHz
Power 125 watts/ch, 20Hz – 20kHz
Multichannel Power(all channels driven) 125 watts/ch
Signal-to-noise Ratio (IHF-A) 100 dB
Input Sensitivity/Impedance 200mV/47k
VIDEO FEATURES
Television Format PAL/NTSC
Input Level/Impedance 1Vp-p/75
Output Level/Impedance 1Vp-p/75
Video Frequency Response (Component Video) 10Hz – 8MHz (–3dB)
HDMI Input / Output : 3D, Audio Return Channel, CEC and Deep Colour
HDMI Version 1.4 a with 3D support
FM TUNER FEATURES
Frequency Range MHz 87.5 MHz
Usable Sensitivity (IHF) 1.3μV/13.2dBf
Signal-to-Noise Ratio (Mono/Stereo) 70dB/68dB
Distortion (Mono/Stereo) 0.2%/0.3%
Stereo Separation @ 1kHz 40 dB
Selectivity ±400kHz 70 dB
Image Rejection 80
IF Rejection 90
AM TUNER SPECIFICATIONS
Frequency Range kHz 520 kHz
Usable Sensitivity (Loop) 500 µV
Distortion 50%, mod 0.8%
Selectivity 30
GENERAL SPECIFICATIONS
Power Requirement AC 230V, 50 Hz
Power Consumption (full power/idle) 120W idle; 1,405W maximum
Dimensions (H x W x D – Metric/English) 440mm x 165mm x 382mm (17-5/16″ x 6-1/2″ x 15″)
Weight (Metric/English) 8kg (17.6 lb)
