PREAMPLIFICATORE PHONO CREEK WYNDSOR

The Wyndsor Phono Pre-Amplifier is the hight of perfection in phono pre-amplifiers. The Wyndsor Phono Pre-Amplifier is designed to deliver the highest level of sound reproduction with its impedance, capacitance and resistor load matching this phono pre-amplifier has the ability to work perfectly with any cartridge.

TECHNICAL SPECIFICATION
GAIN 40dB, 45dB, 53dB, 61dB, 70dB
DISTORTION 0.001%
FREQUENCY RESPONSE 0.5Hz – 100kHz (+/-0.5dB)
IEC ROLL-OFF (7950us) -3dB @ 20Hz -6dB @10 Hz
SNR -76dB
SEPARATION -76dB
DC OFFSET +/-0.1V
INPUT CAPACITANCE 100pF, 440pF, 1.1nF, 1.4nF
INPUT RESISTANCE 91R, 100R, 1k, 33k, 47k
OUTPUT VOLTAGE 10V maximum
INPUTS Unbalanced RCA and Balanced mini DIN sockets
POWER SUPPLY 2x toroidal mains transformers and low noise regulators
SIZE Pre-amp main body = 192mm x 62mm x 195mm WxHxD (Height including feet, depth including the control knob.)Power supply = 112mm x 63mm x 210mm.
WEIGHT Pre-amp = 1.4kg – Power supply = 1.4kg
FINISH COLOURS Black or Silver
