The Evolution 50A sees the start of a new era for Creek Audio. This 55 Watt per channel amplifier continues to deliver Creek’s recognisable high-quality sound whilst maintaining the principle of value for money. This Integrated Amplifier also includes an FM/AM tuner allowing you to enjoy a wide variety of sources.

TECHNICAL SPECIFICATION
POWER OUTPUT >55 Watts into 8 Ohms
POWER OUTPUT >85 Watts into 4 Ohms
CONTINUOUS CURRENT >8.5 Amps (sine wave)
MAX CURRENT >26 Amps, current burst into 0.5 Ohms
OUTPUT IMPEDANCE <0.1 Ohms @ 1Khz THD < 0.005% 20Hz – 20Khz SNR >102dB
FREQUENCY RESPONSE 10Hz – 100KHz +/- 2dB Line
GAIN 33.3dB (x46) via power amp input
INPUT SENSITIVITY 410mV
CROSSTALK -80dB at 1Khz
DC OFFEST < ±10mV SLEW RATE > 30 V per µS
PRE-AMP INPUTS 5x RCA unbalanced – 1x Balanced XLR
POWER-AMP INPUTS Input 3 & 4via RCA or XLR
OUTPUTS 1 Pair
HEADPHONE OUTPUT Dedicated low impedance amp (<50 Ohms) IR BUS Powered output for IR repeater OPERATING VOLTAGES 110V/230V Switchable CONSUMPTION (AT IDLE) <20 Watts CONSUMPTION (AT FULL POWER) 350 Watts WEIGHT 7.5Kgs DIMENSIONS 430x60x280mm W/H/DMC
