AMPLIFICATORE INTEGRATO ICON AUDIO STEREO 60 MK IIIm KT120

New Upgraded Design for 2014!

The Worlds First KT120 Integrated UL/Triode Hi Fi Amplifier!

New Features:
Tertiary Transformers
Valve Regulator
Improved Finish
Plexiglas Valve Cover
Stand By Circuit
An OUTSTANDING Integrated Amp!This is our biggest integrated amplifier. It is ideal for someone wanting a very dynamic fast sound. It has a big power supply, big output transformers, and designed for the excellent new Tung-sol KT150/120. And it comes with many features!

An integrated version of our MB90 MKIIs. The original design got the best out of the KT88, now re-designed for the KT150 which we believe has even better sonics.
The MK III design comes with our new “LDT” low distortion transformers, a valve regulated first stage, and a copper alloy top plate.

Integrated & Power Amplifier in One!
A special feature is the ability to change the sensitivity of Stereo 60 MKIII at the flick of a switch. Choose between use as either an integrated remote control amplifier, or as a power amplifier fed from a separate pre-amplifier.

Triode and Ultralinear Amplifier in One
The triode sound is preferred by many hi fi fans, but the power is always lower. With our UL/Triode switch you can change from 80 watts to 40 watts of pure triode sound by changing the switch.

Specifications and Features
• May be used as a power amplifier
• Comprehensive manual supplied
• Built in bias & valve test meter
• Hand wired point to point
• Japanese Blue ALPS volume pot.
• Class A, Triode front end
• Output circuit Ultralinear or Triode switchable
• 4x KT150/120/KT88/6550 precisely matched*
• 2x 6SL7 first stage valves
• 2x 6SN7 output driver valves
• Valve warm up, protection circuit
• 2x 80 Watts Ultralinear
• 2x 40 Watts Triode mode
• Signal to noise level -90db
• Frequency response 20hz-20kHz +0 – 0.5db full power
• THD less than 0.05% 1khz
• 4 and 8 ohm loudspeaker outputs
• LDT Tertiary Custom hand wound output transformers
• Attractive cover included in the price
• Solen Hi Fi quality audio capacitors
• Jensen copper foil on request
• Silver PTFE audio cable
• Gold plated Input & speaker terminals
• Four line inputs
• Tape monitor circuit
• 350mv input sensitivity.(high) 1.2v (low)
• 220/240volts 200watts typ, 500w max
• C E. ROHS.
• 43cmW, 38D, 23H, 35kg
*Can be de-rated for KT88/6550
