All tests un-weighted and 20Hz – 20kHz measurement bandwidth used.

Frequency response

10Hz – 20kHz, -1dB into 4Ω

Output power

200W rms into 8Ω All channels driven
400W rms into 4Ω Any two channels driven*

Harmonic Distortion

0.018% @ 1kHz All channelsdriven
to 1/8th power into 8Ω

Peak Output Voltage

113V peak to peak, 40V RMS no load
113V peak to peak, 40V RMS into 8Ω

Input Impedance

100kΩ Balanced / 50kΩ SE

Voltage gain

29 dB

Input level at clipping

1.4Vrms Balanced/SE

Intermodulation
Distortion

>80 dB below fundamental into 8Ω SE

Signal to Noise Ratio

-100 dB at peak output into 8Ω (AES17)

Rated power
consumption

200W @ 1/8th power into 8Ω

Mains voltage

100V – 240V, 50/60Hz

Overall Dimensions

Width: 17.00��? (433mm)
Depth (excluding connectors): 14.57��? (370mm)
Height: 3.75��? (95mm)

Net weight

23.1 lb (10.48 kg)

Shipping weight

30.0 lb (13.61 kg)

*each channel supports 400W output into 4 ohms but the AC Mains/power
supply cannot support all channels driven simultaneously at this level, which
would require over 2,500W and only occur under a special test condition.
Every channel easily drives lower impedance loads.
