MOBILE PORTA TV NORSTONE BEOS

DESIGN

Beos – powder coated black – lacquered black



FEATURES

•  Cable management system
•  Adjustable height

DIMENSIONS

• Overall dimensions (W x H x D):
  Min: 45 x 39.4 x 17.7" / 1142 x 1000 x 450 mm
  Max: 47.2 x 47.2 x 17.7" / 1200 x 1200 x 450 mm
• Height without column: 11" / 280 mm
• Shelf A (W x D): 43.4 x 16.5" / 1102 x 420 mm
  Thickness: 0.2" / 6 mm
  Maximum load: 66.1 lbs / 30 kg
• Shelf B (W x D): 43.4 x 16.5" / 1102 x 420 mm
  Thickness: 0.2" / 6 mm
  Maximum load: 66.1 lbs / 30 kg
• Height between shelves:
  7.4" / 187 mm

COLUMN

• Height without arms: 39.4" / 1000 mm
• Column width: 5.5" / 140 mm

TV MOUNT

• Screen from 32" to 50"
• Compatibility: 75, 100×75, 100, 200×100, 200, 300×200, 300, 400×200, 400×300, 400, 600×200, 600×300, 600×400
•
•  Rotating
• Rotation: +/- 12 °
• Horizontal holes distance min: 2.6" / 65 mm
• Horizontal holes distance max: 25.8" / 655 mm
• Vertical holes distance min: 2.2" / 55 mm
• Vertical holes distance max: 18.9" / 480 mm
• Adjustable height min: 39.4" / 1000 mm
• Adjustable height max: 47.2" / 1200 mm
• Maximum load: 110.2 lbs / 50 kg

WARRANTY

• 2 years

UNIT PACKAGING

• Delivered disassembled with screws kit, mounting instructions and tools.
• Quantity/box: 1
• Dimensions (W x H x D):
  48.6 x 6.3 x 21.3" / 1235 x 160 x 540 mm
• Gross weight: 70.1 lbs / 31.8 kg
• Net weight: 56.4 lbs / 25.6 kg
