DIFFUSORE INCASSO KEF Ci130CR

Ci130CR

Featuring the KEF’s unique asymmetrical tweeter island, this configuration reduces high frequency diffraction and aligns the off-axis power response of the tweeter and woofer to make the speaker almost as placement friendly as Uni-Q. Combining impeccable sound quality with the elegant ultra-thin bezel (UTB), the Ci C Series range is part of how to “Hide your speakers, not your sound.”

Features

• UTB™ Ultra Thin Bezel
• Asymmetrical tweeter island for wide off-axis response
• 19mm (0.75in.) Aluminium dome tweeter and ‘tangerine’ waveguide
• 130mm (5.25in.) extended response bass driver

Model Ci130CR
Nominal Impedance 8Ω
Sensitivity (2.83V/ 1m) 87dB
Frequency Response +/-6dB
2pi/open-backed 52Hz – 20kHz
Crossover frequency 4kHz
Drive units LF: 130mm(5.25in.)
MF: –
HF: 19mm (0.75in.)
Recommended amplifier power 10-80W
Product external dimensions Diameter Ø: 193.4mm (7.61in.)
Depth: 83.5mm (3.29in.)
Cut-out dimension Diameter Ø: 158mm (6.22in.)
Mounting depth from surface Product only: 78mm (3.07in.)
Optional rough in frame RIF130R
