DIFFUSORE INCASSO KEF Ci100QR

Ci100QR

The popular Soundlight Series is yet another major innovation form KEF. When installed, Soundlight speakers are so tiny that they blend in with halogen light fixtures yet will amaze you with their astonishing performance, thanks to KEF’s patented Uni-Q’s exceptionally wide dispersion.

Features and Benefits

Purpose built for flush mounting into walls and ceilings these are the latest addition to the KEF Uni-Q Custom Installation series. Providing a compact solution to the problem of Hi-Fi quality sound from an in-wall/ceiling speaker, the Ci100QR consists of a polypropylene cone LF driver with the HF unit mounted at the acoustic centre of the LF unit. The bezel and grill can be painted to match the interior décor.

Applications

The Ci Series Ci 100QR is best suited for high quality music and speech reinforcement applications requiring hi-fi performance
such as:

• Multi Room systems
• Home Theatre systems
• Lounges, Bars, Boutiques
• Boardrooms & Offices
• Airports, Convention Centres, Hotels
• Live Theatre/Concert Hall fill-in
• Houses of Worship
• Sports Arenas

Architectural Specifications

The Ci Series Ci 100QR consist of:
1 X 19mm aluminium dome tweeter 100mm white polyproylene cone with double neo compound magnet system.

Performance of the Ci 100QR shall meet or exceed the following criteria:
frequency response 1 metre on-axis with swept sinewave shall be 120Hz to 22kHz , sensitivity shall be at least 86dB for 2.83V@1m. The 2.83V@1m. The driver impedance shall be 8 ohms.

Model Ci100QR
Amplifier Requirements 10 – 50W
Nominal Impedance 4Ω
Sensitivity (2.83V @ 1m) 88dB
Frequency Response
+/-6dB 2pi/open-backed 80 – 27kHz
Frequency Response
+/-6dB With back can/rear enclosure 110 – 27kHz
Crossover Frequency 3kHz
Drive Units (LF / MF / HF) 100mm / – / 19mm
Recommended Amplifier Power 10-50W
Features Uni-Q Array, Removeable Plastic Back Can
Product External Dimensions
(Diameter / Width / Depth) 127mm (5in.) / – / 148mm (5.83in.)
Cut-out Dimension (Diameter) 118mm (4.65in.)
Mounting Depth from Surface
(Product only / With back can) 100mm (3.94in.) / 145mm (5.71in.)
