Configuration …………………………………………………………………….. Stereo

Power Supply Transformer ………………………………………………. 400VA

Power Supply Capacitance ……………………………………………….. 40,000μF

Class Of Operation – Amplifier ………………………………………….. Class A/B

Single-ended inputs ………………………………………………………….. 4 (RCA)

Mini-jack input ……………………………………………………………………. 1 (1/8”)

Balanced inputs ………………………………………………………………….. 1 (XLR)

Input Sensitivity …………………………………………………………………. 400mV – 3.0V RMS

Input Impedance ………………………………………………………………… 22,000Ω

Preamplifier output ……………………………………………………………. 1 (RCA)

Headphone output………………………………………………………………. 1 ( 1/4” Stereo TRS)

Output Device Type – Amplifier ………………………………………….. Bipolars – 4 per channel

Output Binding Posts …………………………………………………………. shielded

Output Power @ 8Ω …………………………………………………………… 100 Watts per channel

Output Power @ 4Ω …………………………………………………………… 200 Watts per channel

Output Impedance ……………………………………………………………… 0.04Ω

Damping Factor ………………………………………………………………….. > 200

Gain ……………………………………………………………………………………. 37dB

Dynamic Headroom ……………………………………………………………. 3dB

Signal-to-noise Ratio ………………………………………………………….. 110dB @ full power

Maximum Output Voltage ………………………………………………….. 30 Volts

Slew Rate …………………………………………………………………………… 20V/μs

Maximum Current – Peak ………………………………………………….. 22 amperes

Maximum Current – Continuous ………………………………………. 12 amperes

Frequency Response ………………………………………………………… 2Hz – 900kHz +0/-3dB

Crosstalk @ 1kHz ………………………………………………………………. < -88dB

Intermodulation Distortion ………………………………………………… < 0.03%

THD (20Hz – 20kHz @ 1 watt) ……………………………………………….. < 0.015%

THD (20Hz – 20kHz @ 100 watts) ………………………………………….. < 0.05%

Remote Control ………………………………………………………………….. Full-Function (CRM-2)

AC Power Requirements …………………………………………………… 120V / 60Hz or 240V / 50Hz

Shipping Weight …………………………………………………………………. 28 lbs / 13 Kgs

Dimensions (W x H x D, inches) …………………………………………. 16.9 x 3.5 x 14.8

Phono Section:

Input Impedance ……………………………………………………………….. Adjustable – 100 ohms and 47K ohms

Input Capacitance ………………………………………………………………. Adjustable – 0pF and 100pF

Gain …………………………………………………………………………………….. Adjustable 40dB and 60dB

Input overload @ 40dB gain ………………………………………………… 58mV RMS

Input overload @ 60dB gain ………………………………………………… 3mV RMS

Signal-to-noise Ratio (full scale @ 40dB gain) …………………….. 107dBr

Signal-to-noise Ratio (full scale @ 60dB gain) …………………….. 85dBr

Frequency Response ………………………………………………………….. 20Hz – 20kHz (±0.5dB)

Crosstalk @ 1kHz………………………………………………………………… -97dB

IMD ……………………………………………………………………………………… < 0.009%

THD (20Hz – 20kHz) ………………………………………………………………. < 0.001%

Digital-to-Analog Converter:

Digital Input Types …………………………………………………………….. S/PDIF (RCA) x 2 USB x 1 TosLink x 1

Digital Input Impedance (S/PDIF) ………………………………………… 75 ohms @ 0.5 Volts

DAC / Digital Filter ………………………………………………………………. BurrBrown PCM1793

Bit-depth range – S/PDIF, Optical ……………………………………….. 16 – 24 bits

Bit-depth range – USB ……………………………………………………….. 16 bits

Sampling Frequency Rates – S/PDIF, Optical………………………. 44.1, 48, 88.2, 96, 176.4 and 192kHz

Sampling Frequency Rates – USB ……………………………………… 44.1 and 48kHz

Frequency Response (audible) ………………………………………… 20Hz – 20kHz +0/-0.2dB

Frequency Response (full range) …………………………………….. 2Hz – 72kHz +0/-3dB

THD @ 1kHz, 0dBFS (A-weighted) ……………………………………… < 0.001 %

IMD …………………………………………………………………………………….. < 0.004 %

Dynamic Range ………………………………………………………………….. > 116dB

Signal-to-noise ratio ………………………………………………………….. > 115dB @ full output

Slew Rate …………………………………………………………………………… 50V/μs

Channel Separation …………………………………………………………… > 115dB

Low Level Linearity …………………………………………………………… ±1.0dB to below 120dBFS

Intrinsic Jitter ……………………………………………………………………. < 25 picoseconds RMS

Balanced Pin Assignment: Pin 1………………………………………… Ground

Pin 2……………………………………………………………………………………. Positive

Pin 3 …………………………………………………………………………………… Negative

12 Volt Trigger: Logic…………………………………………………………. Direct (0V off, 12V on)

Jack…………………………………………………………………………………….. 3.5mm microphone jack

Input Impedance…………………………………………………………………. 1kΩ

Current Consumption………………………………………………………… 12mA
